model
SC-3000-112, SC-3000-124, SC-3000-212, SC-3000-224
Main Features
◎ All in one design: Bi-direction inverter and charger ◎ Certified by UL458 with marine supplement ◎ Compact design
AC Output Voltage
100/110/115/120VAC ± 3%; 200/220/230/240VAC ± 3%
Surge Power
Load 101%~115% (1 Min) / 6000 VA (2 Sec)
Output Waveform
Pure Sine Wave (THD < 5% @ 12.5V/25V/115VAC, linear load) / (THD < 3% @ 12.5V/25V/230VAC, linear load)
Frequency
50/60 Hz ± 0.3 Hz (User-selectable)
DC Input Voltage Range
10.5 ~ 16.5 VDC; 21 ~ 33 VDC
Operating Temperature
-20℃ ~ 40℃, Power De-rating from 41°C to 60°C
Safety
UL458 & Supplement SA, FCC class A
